FLEX selections	Technical excellence	Simplicity
F L E X Fundamental selection Meet your basic measurement needs	Technical excellence	Simplicity
F L E X Lean selection Handle your core processes easily	Technical excellence	Simplicity
F L E X Extended selection Optimize your processes with innovative technologies	Technical excellence	Simplicity
F L E X Xpert selection Master your most challenging applications	Technical excellence	Simplicity Variable

Learn more about the FLEX selections

Compare

Micropilot FMR43 – radar sensor for hygienic processes

High performance sensor, especially compact and the perfect fit for fast changing level applications

Accuracy +/-1 mm (0.04 in)

Process temperature -40 to +150 °C
(-40 to +302 °F)

Process pressure / max. overpressure limit -1 to +20 bar
(-14.5 to +290 psi)

Max. measurement distance 15 m (49 ft)

Main wetted parts PEEK
PTFE
316L (for threaded connections)

F

L

E

X

Compare

Liquiphant FTL51B - digital, simple and safe

Point level switch for all liquid media

Process temperature -50 °C...+150 °C
(-58 °F...+302 °F)

Process pressure / max. overpressure limit Vacuum...100 bar
Vacuum...1450 psi

Min. density of medium 0.5 g/cm³
(0.4 g/cm³ optional)

F

L

E

X

Compare

Ultrasonic measurement Time-of-Flight Prosonic FDU90

Ultrasonic sensor for level and flow measurement for connection to FMU9x (measuring range up to 3m)

Accuracy +/- 2mm + 0.17% of measured distance

Process temperature -40 °C ... 80 °C
(-40 °F ... 176 °F)

Process pressure / max. overpressure limit 0.7 bar ... 4 bar abs
(10 psi ... 58 psi)

Max. measurement distance Liquids: 3 m (9.8 ft),
Solids: 1.2 m (3.9 ft)

Main wetted parts PVDF (IP68 / NEMA6P)

F

L

E

X

Compare

Ultrasonic measurement Time-of-Flight Prosonic FDU91

Ultrasonic sensor for level and flow measurement for connection to FMU9x (measuring range up to 10m)

Accuracy +/- 2mm + 0.17% of measured distance

Process temperature -40 °C ... 80 °C
(-40 °F ... 176 °F)

Process pressure / max. overpressure limit 0.7 bar ... 4 bar abs
(10 psi ... 58 psi)

Max. measurement distance Liquids: 10 m (33 ft),
Solids: 5 m (16 ft)

Main wetted parts PVDF (fully welded IP68 / NEMA 6P)

F

L

E

X

Compare

Ultrasonic measurement Time-of-Flight Prosonic FDU91F

Hygienic sensor for level and flow measurement for connection to FMU9x (measuring range up to 10m)

Accuracy +/- 2 mm + 0.17% of measured distance

Process temperature -40 °C ... 105 °C
(-40 °F ... 221 °F)
CIP: 30 min: 135 °C
(30 min: 275 °F)

Process pressure / max. overpressure limit 0.7 bar ... 4 bar abs
(10 psi ... 58 psi)

Max. measurement distance Liquids: 10 m (33 ft),
Solids: 5 m (16 ft)

Main wetted parts 316L (fully welded IP68 / NEMA 6P)

F

L

E

X

Compare

Ultrasonic measurement Time-of-Flight Prosonic FDU92

Ultrasonic sensor for level and flow measurement for connection to FMU9x (measuring range up to 20m)

Accuracy +/- 2mm + 0.17% of measured distance

Process temperature -40 °C ... 95 °C
(-40 °F ... 203 °F)

Process pressure / max. overpressure limit 0.7 bar ... 4 bar abs
(10 psi ... 58 psi)

Max. measurement distance Liquids: 20 m (65 ft),
Solids: 10 m (33 ft)

Main wetted parts PVDF (fully welded IP68 / NEMA 6P)

F

L

E

X

Compare

Ultrasonic measurement Time-of-Flight Prosonic FDU93

Ultrasonic sensor for level and flow measurement for connection to FMU9x (measuring range up to 25m)

Accuracy +/- 2mm + 0.17% of measured distance

Process temperature -40 °C ... 95 °C
(-40 °F ... 203 °F)

Process pressure / max. overpressure limit 0.7 bar ... 3 bar abs
(10 psi ... 43 psi)

Max. measurement distance Liquids: 25 m (85 ft),
Solids: 15 m (50 ft)

Main wetted parts UP (unsaturated polyester)

F

L

E

X

Compare

Ultrasonic measurement Time-of-Flight Prosonic FDU95

Ultrasonic sensor for level measurement for connection to FMU9x (measuring range up to 45m)

Accuracy +/- 2mm + 0.17% of measured distance

Process temperature -40 °C ... 80 °C
or 150 °C
(-40 °F ... 176 °F
or 302 °F)

Process pressure / max. overpressure limit 0.7 bar...1.5 bar abs
(10 psi...22 psi)

Max. measurement distance 45 m (148 ft)

Main wetted parts UP (unsaturated polyester)

Deltabar FMD71 - Electronic differential pressure

F

L

E

X

Compare

Electronic differential pressure Deltabar FMD71

Electronic differential pressure system utilizing two ceramic sensor modules and one transmitter

Accuracy 0.075% of individual sensor,
"PLATINUM" 0.05% of individual sensor

Process temperature –25...+150°C
(–13...+302°F)

Pressure measuring range 100mbar...40bar
(1.5psi...600psi)

Process pressure / max. overpressure limit 60 bar (900 psi)

Material process membrane Ceramic
316L, AlloyC

Measuring cell 100 mbar...40 bar
(1.5 psi...600 psi)

Deltabar FMD72 - Electronic differential pressure

F

L

E

X

Compare

Electronic differential pressure Deltabar FMD72

Electronic differential pressure system utilizing two metal sensor modules and one transmitter

Accuracy 0.075% of individual sensor,
"PLATINUM" 0.05% of individual sensor

Process temperature –40...+125°C
(–40 ... +257°F)

Pressure measuring range 400 mbar...10 bar
(6 psi...150 psi)

Process pressure / max. overpressure limit 160 bar (2400 psi)

Main wetted parts 316L, Alloy C

Material process membrane 316L, AlloyC,

Measuring cell 400 mbar...10 bar
(6 psi...150psi)
